JA Solar·SKU TSS-JA-SOLAR-JAM66D45-630-LB-BLACK-FRAME-N-TYPE-DOUB

JA Solar 625W Black Frame N-type Bifacial Solar Module

₦150,000

In stock at Victoria Island, ready for pickup

A 630 W n-type bifacial double glass photovoltaic module from JA Solar's Deep Blue 4.0 Pro range, built with 132 half-cut n-Bycium+ 16BB mono cells in a black frame. The glass-glass construction with 80%±10% bifaciality lets the rear side add yield from reflected light, making it suited to ground-mount, commercial rooftop and carport installations. It carries a 12-year product warranty and a 30-year linear power output warranty with 1% first-year and 0.4% annual degradation.

Rated Maximum Power (Pmax):630 W
Module Efficiency:23.3 %
Open Circuit Voltage (Voc):48.90 V
Maximum Power Voltage (Vmp):40.70 V
Short Circuit Current (Isc):16.18 A
Maximum Power Current (Imp):15.48 A

Order this on WhatsApp instead

Pickup at Victoria Island. Collect from 273A Kofo Abayomi Street once your transfer is confirmed.
Pay by bank transfer. Invoice and account details sent to your WhatsApp after you order.
Installation available. Our engineers install and commission. Request a system quote.
Datasheet. Download the manufacturer PDF (1259 KB).

Specifications

Rated Maximum Power (Pmax): 630 W
Module Efficiency: 23.3 %
Open Circuit Voltage (Voc): 48.90 V
Maximum Power Voltage (Vmp): 40.70 V
Short Circuit Current (Isc): 16.18 A
Maximum Power Current (Imp): 15.48 A
Power Tolerance: 0~+3%
Cell Type: Mono n-type, 132 half-cells (6×22)
Bifaciality: 80%±10%
Pmax at 10% rear irradiation ratio: 680 W
Temperature Coefficient of Pmax (γ_Pmp): -0.290%/°C
Temperature Coefficient of Voc (β_Voc): -0.250%/°C
Temperature Coefficient of Isc (α_Isc): +0.045%/°C
Maximum System Voltage: 1500 V DC
Maximum Series Fuse Rating: 35 A
Operating Temperature: -40°C~+85°C
NOCT: 45±2°C
Dimensions: 2382±2mm × 1134±2mm × 30±1mm
Weight: 33.1 kg
Front / Back Glass: 2.0 mm / 2.0 mm
Junction Box / Connector: IP68, 3 diodes / QC 4.10-351, MC4-EVO2A
Maximum Static Load (Front / Back): 5400 Pa (112 lb/ft²) / 2400 Pa (50 lb/ft²)
Safety Class / Fire Performance: Class II / UL Type 29, Class C
Warranty: 12-year product warranty, 30-year linear power output warranty
Certificates: IEC 61215, IEC 61730, UL 61215, UL 61730; ISO 9001:2015, ISO 14001:2015, ISO 45001:2018, IEC 62941:2019
