Schneider·SKU TSS-SCHNEIDER-HOMAYA-PRO-S6000-6KW-48V

Schneider Homaya Pro 6kW 48V Solar Hybrid Inverter (AEH-SP01-S6000)

₦939,700

In stock at Victoria Island, ready for pickup

The Homaya Pro S4000 is a 4 kW, 48 V transformer-based solar off-grid hybrid inverter with a built-in MPPT solar charge controller and an AC (grid) battery charger. It is intended for homes, small offices, fuel stations, healthcare centres, schools and telecom sites in areas with unreliable or no grid supply, and it works with flooded, gel, AGM and LiFePO4 batteries using selectable charging profiles. Up to 6 units can be paralleled for a combined 24 kW output, and the unit is monitored and configured through its front LCD or an optional Wi-Fi dongle for local phone monitoring without internet.

Continuous output power (up to 40 °C):4000 W / 4000 VA
Overload 15 min / 60 s at 25 °C:5000 W / 6000 W
Surge rating for 10 s:35 A
Continuous output current at 40 °C:17.4 A
Output voltage / waveform:L-N: 230 V +/- 10%, Sinewave
Output frequency (selectable):50/60 Hz (±0.3 Hz)

Order this on WhatsApp instead

Pickup at Victoria Island. Collect from 273A Kofo Abayomi Street once your transfer is confirmed.
Pay by bank transfer. Invoice and account details sent to your WhatsApp after you order.
Installation available. Our engineers install and commission. Request a system quote.
Datasheet. Download the manufacturer PDF (693 KB).

Specifications

Continuous output power (up to 40 °C): 4000 W / 4000 VA
Overload 15 min / 60 s at 25 °C: 5000 W / 6000 W
Surge rating for 10 s: 35 A
Continuous output current at 40 °C: 17.4 A
Output voltage / waveform: L-N: 230 V +/- 10%, Sinewave
Output frequency (selectable): 50/60 Hz (±0.3 Hz)
Battery / DC input voltage range: 40 V to 64 V (48 V nominal)
Maximum input DC current: 125 A
Idle power consumption: <25 W
MPPT solar charger: 60 A max charge current, 3000 W max output power
PV input voltage range (Vmp/Voc) / max voltage: 80 V to 250 V DC / 300 V DC
PV input maximum power: 3200 Wp
AC charger max charge current: 35 Amps
AC input voltage range / max current: L-N: 165 V - 265 V / 40 A
Transfer relay rating / transfer time: 40 A / < 10 mS
Inverter peak efficiency: 91%
MPPT peak efficiency / tracking efficiency: 95% / 99%
Compatible battery types: Flooded, Gel, AGM, LiFePo4
Scalability: Up to 6 inverters in parallel, 1-Ph, 230 V (up to 24 kW)
Motor load: Up to 3HP
Product dimensions (H x W x D): 563.5 x 264 x 183.3 mm
Product weight / shipping weight: 28 kg / 29.6 kg
IP degree of protection: IP 20, recommended for indoor usage
Operating air temperature / humidity: -15 °C to 40 °C / 5% to 95% RH
Storage temperature: -25 °C to 60 °C
Communication ports: RS485-1 for BMS (LFP battery), RS485-2 for Wi-Fi dongle
Certification: CE, RoHS, SONCAP; Safety IEC 62109-1, IEC 62109-2; EMC IEC 62040-2
